Three Axle Skeleton Container Semi Trailer 40t

The most acclaimed three axle skeleton container semi-trailer of 2024, 40T, has an integral long crossbeam installed in the middle container locking device to improve the load-bearing capacity of the container locking device. The difference between flat panel and skeleton style lies in the addition of frames and patterned flooring.

Send Inquiry

Product Description

The frame of the three axle skeleton container semi-trailer 40T is all shot peened, and the entire frame is assembled and welded on a dedicated positioning platform. Its structure is reasonable, high in strength, and beautiful in appearance. A container compression device is installed on the frame, which can load two standard containers of 40 feet and 20 feet.

Product Parameter

Three Axle skeleton Container Semi Trailer
Tare weight	7000kg
Size	12500mm2500mm1550mm
Payload	40TON
Main beam	Heavy duty and extra durability designed I beam; opting for high tensile steel Q345, welded by automatic submerged-Arc processes. Top flange 14 mm;bottom flange 16mm；Middle Flange 8mm， height 500mm;
Axle	FUWA brand 13Ton*3axles
Suspension	Mechanical suspension american type
Leaf spring	Leaf spring 10pcs9013mm*6sets
Tire	12R22.5 *12pcs
Wheel rim	9.0-22.5*12pcs
Kingpin	3.5”bolted type king pin
Landing gear	28Ton two-speed, manual operating ,heavy duty landing gear
Twist lock	12pcs
Braking system	WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks
ABS	Option
Electrical	Voltage 24V, Receptacle 7 ways (7 wire harness), Side marker lamp LED type, Tail lamp with turn signal, brake light & reflector, One set 6-core standard Cable
Painting	Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint,Wax spray
Accessories	One standard tool box、one spare tire carrier、one crank、one shaft head wrench、
Packing	Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice

Introduction of production process

A.Steel auto cutting

B.Main beam auto submerged arc welding

C.Chassis reversal ensure every part been welding well

D.Shot blasting for rust cleaning

E.F.Welding by experienced worker

G.Final cleaning welding slag by worker

H.Dust-free painting line

Our flatbed truck semi trailer with multi-function , It's designed to carry long log , tube , 20ft 40ft container or bulk cargo. Our flatbed trailer can be match with SHACMAN , HOWO , FAW , BENZ , VOLVO , HINO , MAN and other brand tractor truck well. In this case , our truck semi trailer makes the transportation much more flexible .

Main Features

Container Flatbed Semi Trailers, offer the container trailers to maximize the payload. Our flatbed container trailer adopt advanced design concept. After fully understanding and analysing the transportation environment in different countries. Also the length of the trailers can be customized, like 45ft, 48ft, or 53ft container transportation trailers.

Our Container flatbed trailer is designed for stevedoring and transporting 1x40', 1x 20'or 2x20'ISO Cargo Containers and loose cargos. To make sure the servise life of the semi trailers, all the apare parts we adopt are World Famous brand. We use famous German WABCO braking valve will definitely shorten the Braking Distance, to make the safety of the trailers and the drivers. Also the trailers floor is checker plate, this will keep the other bulk cargo more stable, like the bags, or long stuff.
