Two Axle Skeleton Container Semi Trailer 35t

The latest double axle skeleton container semi-trailer of 35T in 2024 is a skeleton type vehicle, which is welded from longitudinal beams, crossbeams, and front and rear end beams. The longitudinal beams are made of high-quality steel plate 16Mn submerged arc welded into an I-shaped shape (with main dimensions of 450 and 500), and the crossbeams are stamped into grooves using high-quality steel plates. The front and rear end beams are welded rectangular cross-sections.

Send Inquiry

Product Description

The double axle skeleton container semi-trailer is 35T. When loading containers, the locking device of the middle container can be lowered below the plane of the receiving platform as needed.

Product Parameter

Two Axle skeleton Container Semi Trailer
Tare weight	5300kg
Size	12500mm2500mm1550mm
Payload	35 TON
Main beam	Heavy duty and extra durability designed I beam; opting for high tensile steel Q345, welded by automatic submerged-Arc processes. Top flange 14 mm;bottom flange 16mm；Middle Flange 8mm， height 500mm;
Axle	FUWA brand 13Ton*2axles
Suspension	Mechanical suspension american type
Leaf spring	Leaf spring 13mm90mm10 pcs*4units
Tire	12R22.5 *8pcs
Wheel rim	9.0-22.5*8pcs
Kingpin	3.5”bolted type king pin
Landing gear	28Ton two-speed, manual operating ,heavy duty landing gear
Twist lock	12pcs
Braking system	WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks
ABS	Without
Electrical	Voltage 24V, Receptacle 7 ways (7 wire harness), Side marker lamp LED type, Tail lamp with turn signal, brake light & reflector, One set 6-core standard Cable
Painting	Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint,Wax spray
Accessories	One standard tool box、one spare tire carrier、one crank、one shaft head wrench、
Packing	Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice

Main Features

Container Flatbed Semi Trailers, offer the container trailers to maximize the payload. Our flatbed container trailer adopt advanced design concept. After fully understanding and analysing the transportation environment in different countries. Also the length of the trailers can be customized, like 45ft, 48ft, or 53ft container transportation trailers.

Our Container flatbed trailer is designed for stevedoring and transporting 1x40', 1x 20'or 2x20'ISO Cargo Containers and loose cargos. To make sure the servise life of the semi trailers, all the apare parts we adopt are World Famous brand. We use famous German WABCO braking valve will definitely shorten the Braking Distance, to make the safety of the trailers and the drivers. Also the trailers floor is checker plate, this will keep the other bulk cargo more stable, like the bags, or long stuff.

Introduction of production process

A.Steel auto cutting

B.Main beam auto submerged arc welding

C.Chassis reversal ensure every part been welding well

D.Shot blasting for rust cleaning

E.F.Welding by experienced worker

G.Final cleaning welding slag by worker

H.Dust-free painting line

Our flatbed truck semi trailer with multi-function , It's designed to carry long log , tube , 20ft 40ft container or bulk cargo. Our flatbed trailer can be match with SHACMAN , HOWO , FAW , BENZ , VOLVO , HINO , MAN and other brand tractor truck well. In this case , our truck semi trailer makes the transportation much more flexible .
