Four Axles 60CBM Oil Tank Semi Trailer

The latest four axle 60cbm oil tank semi-trailer in 2024 is a semi-trailer with a tank structure for its cargo carrying area. Mainly used for transporting liquids, bulk materials, and bulk cement.

Send Inquiry

Product Description

Four axle 60cbm oil tank semi-trailer, the tank body is designed in 3D and manufactured using advanced processing technology. Chassis adopts special chassis from various manufacturers, with advanced technology and reliable performance. A truck carrying canned containers. Advantages: High efficiency in loading, unloading, and transportation. Ensure the quality of the goods.

Product Parameter

FOUR AXLE OIL TANK SEMI-TRAILER SPECIFICATIONS
Dimension(mm)	13400x2550x41550mm
Tare weight	11000kg
Volume	Approx 60000Liters
Tank body	5mm Q235 steel
Seal head	6mm Q235 steel
Baffles plate	4mm Q235 steel
Compartment	4units
Manhole cover	Diameter：500mm;Material :Q235;Number :4 pcs
Discharging valve	Diameter :3 inch; Material :standard ;Number :4pcs
Wave-proof plate thickness	4mm
Bottom safety valve	4 inch
Discharging pipe	3 inch ;Rubber hose,2pcs
Cat walk	Standard
Axle	Fuwa Brand 13T*4axles
Suspension	Mechanical suspension
Leaf spring	Leaf spring 10pcs9013mm*
Tyre	12.00R20 Tyre *16sets
Wheel rim	8.5-20 steel wheel rim *16pcs
Kingpin	3.5’’bolt-in king pin
Landing gear	28T Two-speed, manual operating ,heavy duty landing gear
Braking system	WABCO RE6 Relay Emergency Valve.T30/30 spring brake chamber.40L air tanks
ABS	Without
Electrical	Voltage 24V, Receptacle 7 ways (7 wire harness), Side marker lamp LED type
Painting	Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint. Wax spray
Accessories	One tool box, One spare tire carrier ,One crank, One shaft head wrench.
Packing	Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice
