Tyre Wheel Mobile Hydraulic Cone Crushing

The Quan Yu's high-quality tyre wheel mobile hydraulic cone crushing is a high-yield and effective mobile crushing station that can directly select the site and drive it to the site without transportation, achieving the finished product particle size directly. It is especially suitable for small crushing sites and is suitable for construction waste treatment and crushing.

Send Inquiry

Product Description

Quan Yu's high-quality Tyre Wheel Mobile hydraulic Cone Crushing Plant is not limited to the location of crushing operation, and it reduces the cost of material transportation. The Mobile Cone Crushing Plant can crush materials on site or somewhere near the work site.Mobile Hydraulic Cone Crusher/Symons Cone Crusher Plant.

Applications: Mobile crushing + screening plant: used for secondary crushing process, can achieve more complex processing by optimal combination. Mobile screening plant: used for screening worked with other crushers

Feeding Opening: 8-50mm

Capacity: 50-350 tph

Applications: mining industrial, coal mines, garbage and construction waste, earth and stone works, urban infrastructure, roads or construction sites.

Applicable materials: river pebble, rock (limestone, granite, basalt, diabase, andesite, etc.), ore tailings

Product Parameter

Tyre Wheel Mobile Hydraulic Cone Crushing Plant
Model		Y2S1548C75	Y2S1860C1300	Y3S2160H220
Transportation Length(mm)		12600	13500	14500
Transportation Width(mm)		2600	2700	2800
Transportation Height(mm)		3870	4200	4450
Maximum Length(mm)		12500	14000	16100
Maximum Width(mm)		4100	4500	5100
Maximum Height(mm)		4100	4900	5000
Weight(t)		39	57	55
Tire Configuration		Dual-axial	Dual-axial	Dual-axial
Hydraulic Cone Crusher		C75	C1300	HPC220
Maximum Feeding Size(mm)		500	550	660
Discharge Opening Size(mm)		50-150	75-175	100-200
Capacity(t/h)		85-275	110-350	215-510
Vibrating Screen Model		Y1548	Y1848	Y1860
Main Belt Conveyor		B500×7M	B650×7M	B650×8M
Side-opening Belt conveyor(Optional)		B500×3M	B650×3.5M	B650×4M
Genset(Optional) (kw)		200	250	270
Iron Separator (Optional)		RCYD(C)-8	RCYD(C)-10	RCYD(C)-10
Packing	Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice

Advantages

The body frame can update the crushing unit as the carrying platform. Three model of mobile screening plant can be chosen. Nine models of cone crushing plant and six models of impact crushing plant can be chosen. When there is in need of medium and fine cone crusher for the two parts or three parts crushing plant, the customers can choose the suitable model from the ZYS, ZYC and PYB series.this cone crusher combine the crushing stroke, speed and the cavity perfectly, which makes the mobile crushing plant outstanding on the aspect for the performance, efficiency, capacity and quality.

FEATURES:

1,From single equipment to multiple combinations

2,New addition with large capacity

3,Reliable fine size crusher

4,Enhance the capacity of the crusher by adjusting the angle of the vibrating screening.

5,Customizing our customers' needs by changing the main equipment

6,Easy stop the mobile crusher and ready for work mode quickly

Structure

The parts of mobile jaw crusher plant includes: frame, jaw crusher, feeder, vibrating screen, belt conveyor, motor and control box.

Usage Scope

1. It is widely used in mine, quarrying, rubbish, the recycling of construction waste, earth and stone works, urban infrastructure, road, building site and so on.

2. Handle topsoil and other various materials; separate viscidity coagulation aggregate; the screening after crushing.

3. Manufactured sand for river gravel, hillstone (limestone, granite, basalt, diabase, andesite, etc., ore tailings, aggregate chips and so on.

Technical Data of Mobile Cone Crusher Plant
