Four Axle Low Bed Semi Trailer

The best four axle low bed semi-trailer is usually used to transport heavy vehicles (such as tractors, buses, specialized vehicles, etc.), rail vehicles, mining machinery, forestry machinery, engineering machinery (such as excavators, bulldozers, loaders, pavers, cranes, etc.), and other heavy-duty goods. The lower the center of gravity, the better the stability and safety, and the stronger the ability to transport ultra-high goods and pass overhead obstacles.

Send Inquiry

Product Description

A four axle low bed semi-trailer is a specialized trailer for transporting engineering machinery, excavators, pavers, mineral machinery, and other equipment. Excellent craftsmanship, compact structure, stable form, low cost, and year-round supply.

Product Parameter

FOUR AXLE LOW-BED SEMI TRAILER SPECIFICATIONS
Weight
Total gross weight approx.	84000kg
Dead weight approx.	14000kg
Payload approx.	70000kg
Dimensions
Total length outside approx.	17500mm
Total width outside approx.	3000mm
Total height outside approx.	1710mm( adjustable according to the height of king pin plate)
Total length of platform approx.	13500mm
Total width of platform approx.	3000mm
Total height of platform approx.	1080mm
Chassis
Main bean	Material: Q345B carbon steel; Type: gooseneck type; Height: 500mm; Upper plate: 20mm； Bottom plate: 20mm Double Middle plate: 10+10mm Process: welded by automatic submerged-acr
Cross member	12#C type or AB type
Side rail	350# "工" type
king pin	3.5"
Platform
Platform	Q235, checkered plate, 5mm,
Hole / lashing	12pcs per side,24pcs in total
Hook	9pcs per side,18pcs in total
Running System
axle	Capacity: 16T / axle3 units
suspension	Mechanical suspension with beam equaliser; Spring size: 90mm*16mm; Spring QTY: 10+10+10+10
tyres	Brand：Chengshan Type:8.25R20 Double mounted; QTY: 16PCS
wheel	20*8.5, 16pcs
Landing legs	28T total Lifting capacity and 50T static capacity,two speeds, two-sides operation
Brake system	Type: Dual line braking system Brake air chamber: 6 in total, T30/304 + T302 Air tank: 40L*2 unit ABS: none
Accessories
Rear Loading Ramps	2 units. spring loaded & manually operated with safety chain
Tool Box	1 pc
Spare Wheel Bracket	1 pcs
Electric system	24V LED light; waterproof wire; 7 ways (7 wire harness);Tail lamp with turn signal & brake light & side lamp & reflector etc.
Protectors	Mudguard;Mid & Rear Side protection;
Packing	Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
The manufacturer reserves the right of technical alteration /change for better improvement without prior notice

Product Characteristics:

Standard Type

Low load bearing surface,low transport gravity center of cargo,and low transport and repair costs.

1,High bearing capacity

2,Lower bearing surface

3,Applicable scope

Heavy Type

High configuration determines high bearing capacity for transport of medium and heavy cargos.

High quality realizes the trouble-free throughout the whole transport.

High benefit is beyond your expectation.

1,Lower bearing surface

2,High bearing capacity

3,New ladder
